Mobile Jaw Crusher CT 740

DSC_0123

PRODUCT FEATURES

It is for you, when you need a compact crusher with a heavy-duty, which can have excellent performance when used in a various range of applications; from recycling to quarrying. It is powerful to work in coal, limestone, gypsum, silica, flint, dolomite, and gravel, as well as tile, concrete, and clinker.

Having a by-pass belt for the pre-crushing screen, its durability and sustainability are longer which decreases its maintenance costs. It is small enough to fit inside a container; an impressive specification that lets CT 740 one step in front among its counterparts.

CT 740 comes complete with a diesel engine and track system. The self-contained machine can be powered from that high-performing hydraulic drive. Jaw crusher can be adjusted hydraulically, so, changing the product size takes less than one minute.

Its quick set-up times, ease of transport, and ease of use are its advantages to be distinguished among mobile crushers.

Net Engine Power100 kW / 105 kW (134 HP / 140 HP)
Inlet Opening700 x 400 mm (2’ 3.5” x 1’ 3.7”)
Operating Weight17,500 kg (38,580 lbs)
Transport DimensionsHeight 2550 mm (8’ 4”) | Width 2156 mm (7’ 1”) | Length 11900 mm (39’ 0”)
Working DimensionsHeight 2900 mm (9’ 6”) | Width 2156 mm (7’ 1”) | Length 11900 mm (39’ 0”)
